Home / Products / Optoelectronics / LED Indication - Discrete / HSMF-C114
Broadcom Limited HSMF-C114
- MFG Part Number
- HSMF-C114
- Available Quantity
- 51550 Pieces
- Reference Price
- USD 0.574488
- Our Price
- We have a big discount, please contact us
- Shipping Date
- We can ship out today
- Manufacturer
- Broadcom Limited
- Brief Description
- - LED RGB DIFFUSED CHIP SMD
- Lead Free Status / RoHS Status
- RoHS Compliant (Lead Free)
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Date Code (D/C)
- New
- Product Category
- LED Indication - Discrete
- Stock Resource
- Franchised Distributor
- Warranty
- 360 days quality guarantee
- Datasheet
- HSMF-C114.pdf
HSMF-C114 Specifications
| Manufacturer Part Number | HSMF-C114 |
|---|---|
| Future Part Number | FT-HSMF-C114 |
| SPQ / MOQ | Contact Us |
| Packing Material | Reel/Tray/Tube/Others |
| Series | - |
| HSMF-C114 Status (Lifecycle) | In Stock |
| Part Status | Active |
| Color | Red, Green, Blue (RGB) |
| Configuration | Common Anode |
| Lens Color | White |
| Lens Transparency | Diffused |
| Millicandela Rating | 85mcd Red, 180mcd Green, 70mcd Blue |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 1.10mm x 1.50mm |
| Voltage - Forward (Vf) (Typ) | 1.9V Red, 3.4V Green, 3.4V Blue |
| Current - Test | 20mA Red, 20mA Green, 20mA Blue |
| Viewing Angle | 140° Red, 145° Green, 145° Blue |
| Mounting Type | Surface Mount |
| Wavelength - Dominant | 626nm Red, 525nm Green, 470nm Blue |
| Wavelength - Peak | 637nm Red, 523nm Green, 468nm Blue |
| Features | - |
| Package / Case | 0606 (1616 Metric) |
| Supplier Device Package | Chip LED |
| Size / Dimension | 1.60mm L x 1.50mm W |
| Height (Max) | 0.35mm |
| Country of Origin | USA/JAPAN/MALAYSIA/MEXICO/CN |
| HSMF-C114 Weight | Contact Us |
| Replacement Part Number | HSMF-C114-FT |
